General Building Data

Building Name: HD Woodson Senior High School
Location: 5500 EADS Street NE, Washington, DC 20019
Site: Former HD Woodson High School facility location (663.572.98 sf or 15.23 acres)
             Bound by:       North-Nannie Helen Burroughs Ave NE
                                       East- 55th Street NE
                                       South- EADS Street NE
                                       West– Division Ave
Building Occupant: Faculty, Staff and Students of HD Woodson Senior High School
Occupancy and Function:
           Center Building: Type IIA Construction
                          Student Dining/Commons Area                                                                                   A-2
                          Gymnasium (w/ Seating) including Locker Rooms                                                A-4
                          Educational Areas                                                                                                             E
                          Business Areas                                                                                                                   B
                          Kitchen                                                                                                                                 B
                          Atrium                                                                                                                                  Sec. 404 (IBC Reference)
             South Building: Type IIB Construction
                          Auditorium                                                                                                                          A-1
                          Classrooms                                                                                                                          E
                          Projection Room                                                                                                                Sec. 409 (IBC Reference)
                          Stage                                                                                                                                      Sec. 410 (IBC Reference)
             North Building: Type IIA Construction
                          Auxiliary Gymnasium (w/Seating) including Locker Rooms                               A-4
                          Natatorium (w/ Seating) including Locker Rooms                                                 A-4
                          Educational Areas                                                                                                             E
                          Business                                                                                                                               B
                          Stores                                                                                                                                   M
             All Buildings
                          Automatic Sprinklers                                                                                                       NFPA 13
                          Standpipe System (at Stage per Sec. 905.3.4)                                                          NFPA 13
                          Portable Fire Extinguishers                                                                                           IFC 2006
                          Manual Fire Alarm                                                                                                            NFPA 72
                          Emergency Voice/Alarm System                                                                                  NFPA 72
Size: 266,000 square feet
Number of stories: Three levels above grade, 1 below– Four total
Primary Project Team:
             Architect
                          cox graae + spack
                          2909 M Street NW
                          Washington, DC 20007

                    Associate Architect
                          SHW Group
                          11415 Isaac Newton Square
                          Reston, VA 20190

                    Design Builder
                          HESS Construction + Engineering Services
                          804 West Diamond Avenue
                          Gaithersburg, MD 20878

                    Civil Engineer
                          WILES MENSCH
                          11860 Sunrise Valley Drive, Suite 200
                          Reston, VA 20191

                    Landscape
                          EDAW|AECOM
                          601 Prince Street
                          Alexandria, VA 22314

                    Structural Engineering
                          ADTEK
                          3251 Old Lee Highway, Suite 405
                          Fairfax, VA 22030

                    M/E/P Engineering
                          SETTY AND ASSOCIATES INTERNATIONAL, PLLC
                          5185 MacArthur Blvd, Suite 106
                          Washington, DC 20016

                    Pool Consultant
                          WATER TECHNOLOGY
                          100 Park Avenue
                          P.O. Box 614
                          Beaver Dam, WI 53916

                    Acoustics
                          POLYSONICS
                          405 Belle Air Lane
                          Warrenton, VA 20186

                    Food Service
                          NYIKOS ASSOCIATES, INC
                          18205-A Flower Hill Way
                          Gaithersburg, MD 20879

                    Code Consultants
                          LAW-MILLER CONSULTING
                          9520 Cape Anne Place
                          Gaithersburg, MD 20886
Dates of Construction:       Erosion and Sediment Control Begins       September 23,2009
                                                                 Substantial Completion                                  August 30, 2011
                                                       Final Completion                                              November 23,2011
Project Delivery Method: Design-Build with CM at Risk
