Building Statistics

Wellington Condominiums

Building Statistics

GENERAL ARCHITECTURE ENVELOPE STRUCTURAL MECHANICAL FIRE PROTECTION ELECTRICAL MASONARY CURTAIN WALL

General Building Data:

Building Name: Wellington Condominiums Location and Site: 614 Wharton Boulevard Exton, PA 19341 at the Eagleview Town Square Building Occupant Name: Wellington Condominiums Occupancy: Separated Mixed Use Groups of R-2 Residential (Specifically 48 Luxury Condominiums) and S-2 Parking Garage Size: 147,069 SF (Including Parking Garage) Number of stories above grade/ total levels: 4 Stories / 5 Levels w/ Parking Garage
Primary Project Team:
Owner:		*The Hankin Group*
General Contractor:		*Wellington Commercial Construction*
Construction Manager:		*Wellington Commercial Construction*
Architects:		*Minno & Wasko Architects and Planner*
Engineers:		*Liberty Engineering*
		*Chester Valley Engineers*
		*Earth Engineering Inc.*
		*Swirnow Structures LLC*
		*American Panel Tec*
Dates of Construction: Start: 9/26/05 Finish: 5/04/07
Actual Cost: $18,105,952 (Overall Project Cost w/ General Conditions. Not including costs of consultants/services/designs for Architectural/Structural, Civil, Geotechnical, and MEP of the Project.)
Project Delivery Method: Design-Build
Major National Codes: 2003 International Building Code 2003 International Mechanical Code 2003 International Fuel Gas Code 2002 National Electric Code 2003 National Standard Plumbing Code National Fire Protection Agency (NFPA 13, NFPA 13R) Americans with Disabilities Accessibility Guidelines (ADDAG)
Residential Zoning Requirements: Uwchlan Township Zoning Ordinance 12 of 1997:
Maximum Building Height: 65 feet Actual Building Height: 58 feet 4 inches Building Coverage: 50% Maximum Building Length: 300 feet Actual Building Length: 267 feet Building Setbacks: 25 feet Maximum Occupant Load: 735 persons *Parking Requirements: 120 peak demand (2.5 / unit)* Maximum Allowable Residential Egress Travel Distance: 250 feet Actual Maximum Residential Egress Travel Distance: 160 feet Accessible Means of Stair Egress Capacity: 240 people *Maximum Allowable Garage Egress Travel Distance: 400 feet* Actual Maximum Allowable Garage Egress Travel Distance: 164 feet
